2. Real-time location and tracking, track playback
3. Support vibration alarm, overspeed alarm, entry and exit of the electronic fence alarm
4. Ultra-small volume, the body is only the size of a cigarette lighter
5. Simple installation, do not press the boot button, on the power is to work
6. Built-in spare battery, illegal demolition immediately alarm reminder
7. Relays can be connected to realize the remote oil and power disconnection function
8. GPS + Beidou + LBS triple positioning (extended WIFI positioning)
Detail
Model Number #：
HS100
Specification：
1. Working Voltage: 9-90V DC
2. Internal Battery Capacity: 100mAh 3.7V
3. Working Temperature: -20°C to+60°C
4. Storage Temperature: -20°C to+70°C
5. GSM Module: MT2503
6. GPS Chip: AT6558
7. Network: 2G
8. GPRS: Class2,TCP/IP built in GSM Module
9. Tracking Sensitivity: -162dbm
10. Navagation Sensitivity: -160dbm
11. Location Accuracy: ＜5m
12. Cold Start: Average 32 seconds
13. Transmission Protocol: TCP
14. Weight: 26.5g (including Internal Battery Capacity)
15. Dimension: 70mm*10mm*13mm
Functions：
1. GPS+AGPS+LBS Multi-Mode Positioning
2. ACC Detection
3. Vibration Alert
4. Burglar Alert
5. Overspeed Alert
6. Low Battery Alert
7. GEO Fence
8. Historical Route
9. Cut off/Resume oil(optional, relay required)
Packing Details：
1. Accessories: Device,User manual, Power cord
2. Weight: 90g/set
3. Box demensions: 12.8*8.7*3.8cm
4. Carton demensions: 42*25.8*25.2 cm
5. Packing: 50 sets/CTN
6. Weight: 4.8kg/CTN
Product Pictures:
